RIDGER DOUBLE ROWS
Double rows ridgers are mounted to tractors by three point linkage system and can be transport by hydraulic system easily.
Ridgers are used for the purpose of making two rows ridges and for opening channel on the cultivated land. It makes double rows ridges in one time and in wished width from 40cm to 80cm by the means of adjustable disc angle. The discs are 660mm and they are optionally produces as plain discs or knotched discs. The disc angles and the disc between space can be adjustable, as well , in order to make in wished width ridges and channels.
Technical
| Specifications | Unit | GDR-4 |
| Number of Discs | pcs | 4 |
| Total Width (W) | mm | 2700 |
| Total Length (L) | mm | 1150 |
| Total Height (H) | mm | 1460 |
| Working Depth | Max.(cm) | 35 |
| Space Between Bodies | mm | Adjustable |
| Disc diameter | mm | 660 |
| Required Power | hp | 60-70 |
